• High quality design and simple operation
• Prevents oxidation
• Impervious barrier between the process chamber and the insulation material
• Easily maintain inert atmosphere
• Horizontal air flow assures uniform thermal performance under all loading conditions
• Differential Air Pressure Switches alert you if loss of pressure or airflow is detected
• Multiple model options for custom test needs
• Quick access for simple inner chamber cleaning
• Easy to use controller

Features

• Heavy gauge steel exterior made from 16 gauge panels
• Enhanced cooling by aluminum finned water stainless steel cooled coil
• High purge cycle removes ambient air
• Pressure relief valve on vent port on top of chamber
• Inert gas flow and chamber pressure regulation monitors
• Water supply connections
• Interior welded vapor tight
• Gas injection systems
• Interior features reinforced 304 stainless steel
• 4 inches of fiber glass insulation
• Exclusive Blue M Eternal heating elements
• Direct drive blower multi-blade centrifugal blower with high-volume air delivery.
• Profiling or single setpoint temperature controls
• High-volume air delivery via a multi-blade centrifugal blower

The following inert gases are approved for these ovens.

• Argon
• Carbon Dioxide
• Helium
• Nitrogen

Performance

• NFPA 86 Class B oven
• Temperature range: 15°C above ambient to 350°C (662°F)
• Uniformity: +/-2% of setpoint
• Control Accuracy: +0.5°C
• Resolution: ±0.1°C
• Performance data (typical): Run-up to 300°C 60 minutes or less

• High quality design and simple operation
• Interior welded vapor tight
• Welded and sealed liner for an impervious barrier between the process chamber and the insulation material
• Horizontal air flow assures uniform thermal performance under all loading conditions
• Differential Air Pressure Switches alert you if loss of pressure or airflow is detected
• Multiple model options for custom test needs
• Quick access for simple inner chamber cleaning
• Easy to use controller

Features

• HEPA filtration system
• Heavy gauge steel exterior made from 16 gauge panels
• Interior features reinforced 304 stainless steel
• Water supply connection
• 4 inches of fiber glass insulation
• Aluminum finned water cooled stainless steel coil
• Differential air pressure switches
• Exclusive Blue M Eternal heating elements
• Direct drive blower multi-blade centrifugal blower with high-volume air delivery.
• Profiling or single setpoint temperature controls
• High-volume air delivery via a multi-blade centrifugal blower

Performance

• NFPA 86 Class B oven
• Temperature range: 15°C above ambient to 250°C (482°F)
• Uniformity: +/-2%
• Control Accuracy: +0.5°C
• Resolution: +0.1°C
• Performance data (typical): Run-up to 250°C 60 minutes or less

• One pass airflow system – introduces fresh air and allows moisture and odors to exit chamber when drying.
• Exceptional Uniformity
• Legendary Blue M reliability
• Flexible options and customizations available

Chamber Sizes

• 1.6 to 20 Cubic Feet

Key Specifications

• Temperature Range: 15ºC above ambient to 350ºC
• Control: +0.5ºC
• Uniformity: +/-2% of setpoint
• Resolution: ±0.1°C
• Run-up to 300°C in 60 minutes or less

Features And Benefits Of The Blue M 146 Series Standard Mechanical Convection Oven

• High quality design and simple operation – lower total cost of ownership
• Horizontal airflow ensures uniform thermal performance under all loading conditions
• Differential air pressure switches alert operators before costly problems with batch runs
• Many different workspace sizes to fit virtually any requirement
• Quick access for simple inner chamber cleaning
• Easy to use controller for repeatable results and less training requirements
• Heavy gauge steel exterior for long lasting performance
• Reinforced Type 304 stainless steel interior resists corrosion and makes cleaning easy
• 4 inches of fiberglass insulation saves energy and provide cool to the touch exterior
• Adjustable air intake and exhaust dampers for flexible testing conditions
• Exclusive Blue M Eterna heating elements for extreme reliability and life
• Infinitely variable control from full recirculation to full one pass to accommodate any processing need
• Profiling or single setpoint temperature controls offer flexible recipe options
• High-volume air delivery via a multi-blade centrifugal blower

Standard Safety Features

• Overtemperature protection
• Safety airflow switch shuts off power to heater if no airflow

• Economical design
• Uninterrupted thermal processing via non-fan airflow system
• Tight temperature uniformity
• Independent and adjustable over-temperature protection against load and oven damage

Features

• Stainless steel interior
• Powder-coated exterior
• Vertical-up gravity convection airflow
• Adjustable shelving with 2 perforated shelves for airflow
• Gravity convection heating method
• Range of sizes
• 2 configurations

Performance

• Temperature Range:

  • 10°C above ambient to 260°C
  • Uniformity: ≤ ± 3%
  • Fluctuation: ≤ ± 1°C

• Long-lasting, tube-style heating elements with superior heat ramp-up and recovery times
• High quality design for maximum temperature uniformity
• Efficient and environmentally friendly operation
• Independent and adjustable over-temperature protection against load and oven damage

Lab Oven Features

• Ergonomic handles and controls
• Stainless steel interior
• Powder coated steel exterior
• Tube-style heating elements
• Extra thick insulation
• Horizontal airflow design
• Adjustable shelving and 2 perforated shelves for airflow
• 2 configuration models: economy and premium

NOTE: These lab ovens cannot be used with any volatile or hazardous materials

Lab Oven Performance

Temperature Range:

• 10°C above ambient to 260°C
• Uniformity: ≤ ± 3°C

Lab Oven Controller

• Overtemperature protection is standard

Lab Oven Options

• Additional perforated shelves
